Welit IR C2360 Wired Sensor Security System

IR C2360 is a ceiling mount infrared motion sensor. The highly sensitive pyro-sensor gives it coverage of 360 at the aperture angle of 120 with the detection reach of 6 meters. It is most suitable for medium sized covered areas. It has highly sensitive pyro-sensor operating as the heart of its system. It detects heat radiated from a body. Segmented lenses divide the whole detection area into passive and active zones. When any warm object like human body moves between the zones, it is detected as a change in voltage by the pyro-sensor. When it detects such movement, it triggers the switching mechanism to operate the connected load. As the pyro-sensor operates by detecting change in the temperature, the ambient temperature plays important role in working of this motion sensor. Maximum detection reach distance mentioned in the technical specifications is measured at the ambient temperature of 25⁰ C. Detection reach distance might change with the change in ambient temperature.
